FP20000Q

The FP20000Q is one of The Loud Factory's flagship Lab Gruppen Clone Amplifiers. With over 30 years of combined experience in the field of Pro Audio engineering, we build "the highest quality clones" with US made transistors and capacitors, backed by a 2-year warranty. These are "The Cadillacs" of Lab Gruppen Clone Amplifiers.

Power Output

The FP20000Q delivers 20,000 watts peak total power across 4 channels. At 8 ohm stereo: 2,500W RMS per channel. At 4 ohm stereo: 4,200W RMS per channel. At 2 ohm stereo: 5,000W RMS per channel. Bridged at 4 ohm: 8,400W RMS. Bridged at 2 ohm: 10,000W RMS.

Performance Specifications

Frequency Response: 6.8 Hz - 34 kHz (+0/-0.2dB). THD: <0.01% (6.8 Hz - 20 kHz at 1W). Signal-to-Noise Ratio: >112 dBA. Channel Separation: >70 dB. Damping Factor: >1000. Input Impedance: 20 kOhm. Gain Options: 23-44 dB (selectable).

Protection & Safety

The FP20000Q features comprehensive protection systems including Auto-Level Control (ACL), Input Gain Management (IGM), AutoRamp, short circuit protection, DC voltage protection, turn-on/off transient protection, current inrush protection, and subsonic/ultrasonic filtering.

Customization

Available in 110V or 220V voltage configurations with 30 amp plug options and different speaker connector options. Our dedicated team helps with system design questions and can help select the right power amplifier to fit any customer's needs and budget.
